A complete Rockchip RK3399 based solution on a standard MXM310 module. It is ready to use, saving your time to make it available on the market. It has a built-in intelligent power management system and supports camera up to 1300M pixel.
Standard MXM connector with dimension 82mm*60mm*4mm
Powerful CPU(hexa-core ARM A72 x 2 + A53 x 4 up to 2.0GHz)
Fast USB 3.0 OTG firmware downloading, no JTAG needed, easy to deploy
Android 7.0, Linux BSP with 3.10 kernel and Ubuntu 14.04 image freely available
Built-in intelligent power management system
Connectivity via 1000M ethernet, 802.11 ac/b/g/n/ac Wi-Fi, 3G, bluetooth 4.1(BLE), NFC, GPS4.1
Display via eDP, MIPI, Display Port and more
Supports camera (MIPI) up to 1300M pixel
SPECIFICATIONS
CPU
RK3399, hexa-core ARM A72 x 2 + A53 x 4 up to 2.0GHz
DRAM
Up to 4GB – 1066MHz
Storage
Up to 128GB eMMC
USB
Two USB 2.0 HOST, two USB 2.0 OTG, two type-C USB 3.0
Video
Two LCD controller up to 4k*2k resolution
Audio
Two I2S
MMC/SDIO
One MMC controller, one SDIO controller
Ethernet
One 10/100/1000M MAC
Wireless
Supports USB/UART/SDIO wireless modules
I2C
Seven I2C buses, up to 400K clock
SPI
Three SPI buses
UART
One debug UART, two application UART
